Workpiece Weight (up to 120% including adapter) (kg) | 0.003 to 0.03 |
Max. Workpiece Diameter (mm) | 80 |
Testing Speed (rpm) | 2600 |
Drive motor (kw) | 0.018 (stepping motor) |
Min. Achievable Residual Unbalance (µm) (1) | 0.5 (mass eccentricity for a workpiece of max. weight) |
Min. Achievable Unbalance (g•mm) | 0.009 |
Weight (kg) | 50 |
Power Supply | Single-phase 100V 10A 1KVA |
Workpiece Weight (up to 120% including adapter) (kg) | 0.01 to 0.3 |
Max. Workpiece Diameter (mm) | 200 |
Testing Speed (rpm) | 2600 |
Drive motor (kw) | 0.06 |
Min. Achievable Residual Unbalance (µm) (1) | 0.5 (mass eccentricity for a workpiece of max. weight) |
Min. Achievable Unbalance (g•mm) | 0.05 |
Weight (kg) | 50 |
Power Supply | Single-phase 100V 15A 1.5KVA |
Workpiece Weight (up to 120% including adapter) (kg) | 0.03 to 1 |
Max. Workpiece Diameter (mm) | 200 |
Testing Speed (rpm) | 2300 |
Drive motor (kw) | 0.06 |
Min. Achievable Residual Unbalance (µm) (1) | 0.5 (mass eccentricity for a workpiece of max. weight) |
Min. Achievable Unbalance (g•mm) | 0.15 |
Weight (kg) | 50 |
Power Supply | Single-phase 100V 15A 1.5KVA |
Workpiece Weight (up to 120% including adapter) (kg) | 0.03 to 1 |
Max. Workpiece Diameter (mm) | 200 |
Testing Speed (rpm) | 2300 |
Drive motor (kw) | 0.1 |
Min. Achievable Residual Unbalance (µm) (1) | 0.5 (mass eccentricity for a workpiece of max. weight) |
Min. Achievable Unbalance (g•mm) | 0.15 |
Weight (kg) | 300 |
Power Supply | 3-phase 200V 10A 3.5KVA |
Workpiece Weight (up to 120% including adapter) (kg) | 0.1 to 3 |
Max. Workpiece Diameter (mm) | 250 |
Testing Speed (rpm) | 2000 |
Drive motor (kw) | 0.4 |
Min. Achievable Residual Unbalance (µm) (1) | 0.5 (mass eccentricity for a workpiece of max. weight) |
Min. Achievable Unbalance (g•mm) | 0.5 |
Weight (kg) | 300 |
Power Supply | 3-phase 200V 10A 3.5KVA |
Workpiece Weight (up to 120% including adapter) (kg) | 0.3 to 10 |
Max. Workpiece Diameter (mm) | 300 |
Testing Speed (rpm) | 1200 |
Drive motor (kw) | 1.5 |
Min. Achievable Residual Unbalance (µm) (1) | 0.5 (mass eccentricity for a workpiece of max. weight) |
Min. Achievable Unbalance (g•mm) | 1.5 |
Weight (kg) | 300 |
Power Supply | 3-phase 200V 20A 7KVA |
Workpiece Weight (up to 120% including adapter) (kg) | 1 to 30 |
Max. Workpiece Diameter (mm) | 500 |
Testing Speed (rpm) | 1000 |
Drive motor (kw) | 2.2 |
Min. Achievable Residual Unbalance (µm) (1) | 0.5 (mass eccentricity for a workpiece of max. weight) |
Min. Achievable Unbalance (g•mm) | 5 |
Weight (kg) | 700 |
Power Supply | 3-phase 200V 30A 10KVA |
Workpiece Weight (up to 120% including adapter) (kg) | 2 to 50 |
Max. Workpiece Diameter (mm) | 600 |
Testing Speed (rpm) | 600 |
Drive motor (kw) | 3.7 |
Min. Achievable Residual Unbalance (µm) (1) | 0.5 (mass eccentricity for a workpiece of max. weight) |
Min. Achievable Unbalance (g•mm) | 10 |
Weight (kg) | 700 |
Power Supply | 3-phase 200V 50A 18KVA |
Workpiece Weight (up to 120% including adapter) (kg) | 3 to 100 |
Max. Workpiece Diameter (mm) | 600 |
Testing Speed (rpm) | 600 |
Drive motor (kw) | 3.7 |
Min. Achievable Residual Unbalance (µm) (1) | 0.5 (mass eccentricity for a workpiece of max. weight) |
Min. Achievable Unbalance (g•mm) | 15 |
Weight (kg) | 700 |
Power Supply | 3-phase 200V 50A 18KVA |
