Detil Produk


1	SHIMADZU Microfocus X-Ray Inspection System
	Model	:	Xslicer SMX-1010

	Specifications :
	Spatial Resolution	:	Equivalent to 5 m on the JIMA RT RC-05 micro chart (theoretical value) (Min. 0.1 modulation transfer function (MTF) for 7 m on the JIMA RT RC-05 micro chart on a carbon plate)
	Maximum Sample Size	:	350 × 450 mm max. 100 mm height max. 5 kg max.
	Fluoroscopic Inspection Stroke	:	Tilt: 60°
	X-Ray Output	:	Maximum Tube Voltage: 90 kV Maximum Tube Current: 250 µA Rated Output: 10 W
	Detector	:	Size of Light Receiving Surface: 64 mm × 57 mm Approximately 1.50 million pixels
	Fluoroscopy FOV (on Carbon Plate)	:	1.9 mm (vertical) × 2.2 mm (horizontal) to 38 mm (vertical) × 43 mm (horizontal)
	Rated Output	:	Single Phase 100 VAC to 240 VAC ±10 % 50/60 Hz, 0.5 kVA
	Weight	:	700 kg
	Operating Environment Conditions	:	Ambient Temperature: 10 to 30 °C Ambient Humidity: 40 to 80 % RH (no condensation)
	External Leakage Dose	:	1 µSv/h or less

2	SHIMADZU Microfocus X-Ray Inspection System
	Model	: Xslicer SMX-1020

	Specifications :
	Spatial Resolution	:	Equivalent to 5 m on the JIMA RT RC-05 micro chart (theoretical value) (Min. 0.1 modulation transfer function (MTF) for 7 m on the JIMA RT RC-05 micro chart on a carbon plate)
	Maximum Sample Size	:	350 × 450 mm max. 100 mm height max. 5 kg max.
	Fluoroscopic Inspection Stroke	:	Tilt: 60°
	X-Ray Output	:	Maximum Tube Voltage: 90 kV Maximum Tube Current: 250 µA Rated Output: 10 W
	Detector	:	Size of Light Receiving Surface: 114 mm × 64 mm Approximately 3.00 million pixels
	Fluoroscopy FOV (on Carbon Plate)	:	2.2 mm (vertical) × 3.8 mm (horizontal) to 42 mm (vertical) × 76 mm (horizontal)
	Rated Output	:	Single Phase 100 VAC to 240 VAC ±10 % 50/60 Hz, 0.5 kVA
	Weight	:	700 kg
	Operating Environment Conditions	:	Ambient Temperature: 10 to 30 °C Ambient Humidity: 40 to 80 % RH (no condensation)
	External Leakage Dose	:	1 µSv/h or less

Xslicer SMX-1010/-1020
