Duramin 160
Produk / Struers Metallography / Hardness Tester / Duramin 160
Duramin-160
| c/n | : 06626101 |
Specifications
| LOADS AND APPLICATIONS | Load range (main loads) | : | 1 kgf - 250 kg |
| Vickers capability | : | No | |
| Knoop capability | : | No | |
| Brinell capabilty | : | No | |
| Rockwell capability | : | Yes | |
| HVT/HVB | : | Yes | |
| ANVILS AND TURRETS | XY-stage or anvil size (mm) | : | Ø 80 |
| Vertical capacity (mm) | : | 300 | |
| Throat depth (mm) | : | 200 | |
| Motorized Z-axis | : | No | |
| Turret positions | : | 1 | |
| Machine weight | : | 95 kg | |
| SOFTWARE AND MODULES | Report editor | : | Yes |
| Data export | : | Yes | |
| INTERFACES AND CONNECTIVITY | Operation | : | Embedded Windows 7 PC with 6.5” touch screen. Mouse and keyboard operation is optional |
| Communication Ports | : | HDMI, VGA, RJ45, WLAN, USB, RS232 | |
| WiFi | : | Yes | |
| Blue tooth | Optional |
Duramin-160 Z
| c/n | : 06626111 |
Specifications
| LOADS AND APPLICATIONS | Load range (main loads) | : | 1 kgf - 250 kg |
| Vickers capability | : | No | |
| Knoop capability | : | No | |
| Brinell capabilty | : | No | |
| Rockwell capability | : | Yes | |
| HVT/HVB | : | Yes | |
| ANVILS AND TURRETS | XY-stage or anvil size (mm) | : | Ø 80 |
| Vertical capacity (mm) | : | 300 | |
| Throat depth (mm) | : | 200 | |
| Motorized Z-axis | : | Yes | |
| Turret positions | : | 1 | |
| Machine weight | : | 95 kg | |
| SOFTWARE AND MODULES | Report editor | : | Yes |
| Data export | : | Yes | |
| INTERFACES AND CONNECTIVITY | Operation | : | Embedded Windows 7 PC with 6.5” touch screen. Mouse and keyboard operation is optional |
| Communication Ports | : | HDMI, VGA, RJ45, WLAN, USB, RS232 | |
| WiFi | : | Yes | |
| Blue tooth | Optional |
