| X-Ray Generator |
Rated Power |
: |
135 W |
| Max. Tube Voltage |
: |
225 kV |
| X-Ray Detector |
|
: |
Flat Panel Detector |
| X-Ray Detector Shades of Gray |
|
: |
16 bit, 65536 shades of gray |
| Max. Sample Size ad Weight |
|
: |
Ø300 mm x H 300 mm, 10 kg max. |
| Max. CT Scan Region |
|
: |
Ø300 mm x H 210 mm |
| CT Data Acquisition Time |
|
: |
20 min to 60 min |
| Max. CT Image Size |
|
: |
2048 x 2048 |
| Measurement Accuracy |
Sphere Distance Error |
: |
±(3.8 + L/50)μm |
| Shield Box Size and Mass |
|
: |
W 2,195 x D 1,561 x H 1,971 mm. Approx 4,000 kg |
| Air Conditioning Unit Size |
|
: |
W 832 x D 961 x H 1,529 mm, Approx. 200kg |
| Specialized Desk Size and Mass |
|
: |
W 1,200 x D 700 x H 1,270 mm, Approx. 50 kg |
| Power Requirements |
Main Unit |
: |
Single-phase, AC 200V ±10%, 50/60 Hz, 4kVA |
| Air-conditioning unit |
: |
Three-phase, AC 200 V ±10%, 50/60 Hz, 2.6 kVA |
| Ground |
: |
Type-D ground (100 ohm max. ground resistance) |
| Control Computer |
: |
Single-phase, AC 100V ±10%, 50/60 Hz, 1.5kVA |
| Air Source |
|
: |
0.6 Mpa to 1 Mpa, 60 SLPM Min. |
| External Leakage Dose |
|
: |
1μSv/h max. |
