New standard of analytical balanceATX/ATY series realized superior performance and budget price with Shimadzu weighing sensor UniBloc.
This model achieve usability and high accuracy as analytical balance.
Touch-Key calibration (ATX series)
Automated calibration can be started by pressing keys. Also, your external calibration weights can be used for span calibration (all models)
Easy Setting best fit to weighting application
Quickly adjust the desired ration of stability and response for every application, even during measurement, with one-touch operation.
WindowsDirect communication function
Send balance data to Excel or other Windows applications without any data communication software installation required. By combining standard Auto print functions with typical spreadsheet functios, even difficult applications can be easily automated.
Connection to Windows Vista and Windows7. （pdf/324KB）
* RS232C interface is needed.
Very large size pan
The pan size of AT series is 91mm dia. It's the biggest one in this class and you can set large container (e.g. flask) easily.
|Repeatability (Standard Deviation)||≤0.1mg|
|Response Time||Approx. 3.0 seconds|
|Operating Ambient Temperature||5-40°C 20-85%|
|Temperature Coefficient Sensitivity (ppm/C)||±2ppm/°C (no condensation)|
|Pan Size (mm) approx.||Φ91|
|Main Body Dimensions (mm) approx.||213(W)×356(D)×338(H)|
|Weight (kg) approx.||6.2||6.0|
|Power requirement||12V, 1A|
