Workpiece Weight (up to 120% including adapter) (kg) | 0.3 to 10 |
Max. Workpiece Diameter (mm) | 400 |
Testing Speed (rpm) | 1200 |
Drive motor (kw) | 1.5 |
Min. Achievable Residual Unbalance (µm) | 0.5 (mass eccentricity for a workpiece of max. weight) |
Min. Achievable Unbalance (g•mm) | 1.5 to 5 |
Size (WxDxH mm) | 584x794x1676 |
Weight (kg) | 300 |
Power Supply | 3-phase 200V 20A 7KVA |
